Name: V Type Rubber Fender 400h High Energy Easy Install Long Service Life Customizable
Brand: Hongruntong Marine Co., Ltd.
SKU: HM-ARF01
Price: 516.00 USD
Availability: InStock

cechy Galeria opis produktu Poprosić o wycenę

cechy

specyfikacje

Product Name: Arch Rubber Fender

Kolor: czarny

Size: Customized

MOQ: 1

Logo: Customized

Cechy: Trwałe materiały

Materiał: NR

Application: Dock Protection

Podkreślić:

Easy Install V Type Rubber Fender

Customizable V Type Rubber Fender

marine V Type Rubber Fender

Podstawowe informacje

Place of Origin: China

Nazwa handlowa: Hongruntong Marine

Orzecznictwo: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS

Model Number: HM-ARF01

Zapłata

Packaging Details: Pallet, Wooden Box

Delivery Time: 5-7 Work Days

Payment Terms: T/T, L/C, D/A, , D/P, Western Union, MoneyGram

Supply Ability: 1000Pcs Per Month

Galeria

V Type Rubber Fender 400h High Energy Easy Install Long Service Life Customizable

opis produktu

V Type Rubber Fender 400h High Energy Easy Install Long Service Life Customizable

Dimensions

Description

Arch Rubber Fenders offer a great balance between performance and cost, making them a popular choice for small harbors and large commercial ports alike. Available in a wide range of sizes and configurations, they can be tailored to suit different vessel types and berth structures. Their durability, low maintenance needs, and simple installation make them a smart long-term investment.

Specifications

Product Name	Arch Rubber Fender
Material	Natural rubber, Silicone rubber
Colour	Black, or customized
Surface	Smooth
Size	Height	200-1000mm
	Length	1000-3500mm
	All sizes can be customized
Physical Properties	Polymer Content	100% virgin
	Working temperature	-50℃~240℃
	Tensile strength	≥16 mpa
	Density	90+/-5 Per 100mm in
	Hardness	50-70 (shore A)
	Elongation	≥400%
Features	1. Through high temperature resistant
	2. Excellent tear resistant, oil resistant, aging resistant
	3. Resistant to industrial acid & alkali and good elastic
	4. Built as per PIANC2002
Application	Multi-Purpose-Terminals, RoRo ramps, Passenger Vessel Terminals, Barge

Model	W	B	F	C	H
Model	[mm]	[mm]	[mm]	[mm]	[mm]
HM-ARF200H	400	320	145	128	200
HM-ARF250H	500	410	175	160	250
HM-ARF300H	600	490	225	196	300
HM-ARF400H	800	670	300	260	400
HM-ARF500H	1000	840	375	325	500
HM-ARF600H	1200	1010	450	390	600
HM-ARF800H	1600	1340	600	520	800
HM-ARF1000H	2000	1680	750	650	1000

V Type Rubber Fender 400h High Energy Easy Install Long Service Life Customizable 0

Feature

Excellent Angular Performance
Maintains energy absorption even when vessels approach the berth at an angle, reducing the risk of fender failure.

Corrosion-Resistant Hardware
Typically used with galvanized or stainless-steel mounting bolts and brackets for long-term resistance in marine environments.

Environmentally Stable Material
Rubber retains elasticity and strength in both hot and cold climates without cracking or excessive hardening.

Cost Effective Protection Solution
Offers a great balance of performance, durability, and price—minimizing long-term operating costs for ports and operators.

Applications

► Container terminals

► Bulk cargo berths

► Tanker ports

► Naval bases

Advantages

Over 30 Years of Industry Expertise
With three decades of manufacturing experience, we deeply understand port protection requirements and fender performance optimization.

ISO Certified Production Facility
Our factory operates under ISO 9001 and ISO 14001 quality and environmental management systems, ensuring consistent and compliant output.

In House Rubber Mixing and Vulcanization
We control every step of rubber formulation and curing to ensure superior mechanical properties and long-term durability.

Customized Fender Engineering
We offer tailor-made solutions in size, hardness, and performance based on specific port and vessel requirements.

FAQ

1. What is the maximum energy absorption of Arch Rubber Fenders?
This depends on size and design but can reach several hundred kJ per meter of fender length for large models.

2. How quickly can you deliver Arch Rubber Fenders?
Typical lead time ranges from 4 to 8 weeks depending on order size and customization requirements.

3. Do you offer technical support for fender selection and installation?
Yes, we provide expert engineering consultation, layout design, and installation guidance worldwide.

4. What warranties do you provide for your Arch Rubber Fenders?
We offer standard warranties covering manufacturing defects and material quality, usually 12 to 24 months after delivery.

V Type Rubber Fender 400h High Energy Easy Install Long Service Life Customizable 1
